PXZ

Bomba centrífuga de autocebado

Descripción técnica
Nueva bomba centrífuga de autocebado
Diseño original de pureza (patente)
• motores cuadrados y circulares disponibles
Motor de alta eficiencia ye3, clase de protección ip55 F
Carcasa de la bomba con recubrimiento anticorrosivo
Impulsor de acero inoxidable Aisi 304 o hierro fundido
El eje está hecho de acero inoxidable Aisi 304 o hierro galvanizado
• succión y descarga en hilos G20
Rodamientos NSK de alta calidad, sellos mecánicos resistentes al desgaste
3D PRODUCT CHAT NOW


NEW/NUEVO


TECHNICAL DESCRIPTION
· New self-priming centrifugal pump
· Original design by PURITY (patented)
· Both square motor & round motor available
· YE3 high efficient motor, with protection IP55 class F
· Pump case with anti-corrosive coating
· Impeller in stainless steel AISI 304 or cast iron
· Shaft in stainless steel AISI 304 or galvanized iron
· Suction and discharge port in G20 thread
· Quality NSK bearing, wear resistance mechanical seal



APPLICATIONS / APLICACIONES
· Suitable for use with liquids that are not chemically aggressive towards the materials from which the pump is made.
· The self-priming centrifugal pumps are recommended for use in water supply systems,washing systems, pressure systems, irrigation pumps, liquids transfer.


USING LIMITS
·Liquid temperature between -10℃ and +120℃
·Ambient temperature up to +50℃
·Max. working pressure 16 bar
·Continuous service S1


PATENTS / PATENTES
· Registered model PXZ
· Registered Patent Design no 201530016935.4




NEW/NUEVO


TECHNICAL DESCRIPTION
· New self-priming centrifugal pump
· Original design by PURITY (patented)
· Both square motor & round motor available
· YE3 high efficient motor, with protection IP55 class F
· Pump case with anti-corrosive coating
· Impeller in stainless steel AISI 304 or cast iron
· Shaft in stainless steel AISI 304 or galvanized iron
· Suction and discharge port in G20 thread
· Quality NSK bearing, wear resistance mechanical seal


APPLICATIONS / APLICACIONES
· Suitable for use with liquids that are not chemically aggressive towards the materials from which the pump is made.
· The self-priming centrifugal pumps are recommended for use in water supply systems,washing systems, pressure systems, irrigation pumps, liquids transfer.


USING LIMITS
· Liquid temperature between -10℃ and +120℃
· Ambient temperature up to +50℃
· Max. working pressure 16 bar
· Continuous service S1



PATENTS / PATENTES
· Registered model PXZ
· Registered Patent Design no 201530016935.4
