PZW

Self-priming non-blocking sewage pump Bomba de aguas residuales autocebante Pompe d'égout autobloqua

TECHNICAL DESCRIPTION
· Self-priming non-blocking sewage pump design
· Impeller in two vanes,non-clogging,close but big fluid channels
· Bare shaft pump seperate or coupled with motor both available
· YE3 high efficient motor, with protection IP55 class F
· Stainless steel 304 all wetted parts available for all models
· High efficiency thanks to the excellent hydraulic model is adopted
· Strong drainage capacity with non-blocking design
· Good self-priming performance 4.5-6.0m
3D PRODUCT CHAT NOW


NEW/NUEVO


TECHNICAL DESCRIPTION
· Self-priming non-blocking sewage pump design
· Impeller in two vanes,non-clogging,close but big fluid channels
· Bare shaft pump seperate or coupled with motor both available
· YE3 high efficient motor, with protection IP55 class F
· Stainless steel 304 all wetted parts available for all models
· High efficiency thanks to the excellent hydraulic model is adopted
· Strong drainage capacity with non-blocking design
· Good self-priming performance 4.5-6.0m

APPLICATIONS
· A liquid storage chamber is provided in the pump body,suitable for chemical,petroleum,pharmaceutical,mining,papermaking,fiber,pulp, textile,food,power plant and municipal sewage works,public facilities sewage,river pond breeding and other industries.


USING LIMITS
· Liquid temperature between -10°C and +80°C
· Ambient temperature between -10°C and +50°C
· PH 6-9 for cast iron, 2-13 for stainless steel

· Media weight not exceed 1240 kg / m³
