الكهربائية الطرد المركزي مضخة حريق نهاية شفط اقتران المحرك ( psm60 هرتز )

• جديد EN733 مضخة الطرد المركزي القياسية ، مع محرك
• نقاء التصميم الأصلي ( براءات الاختراع )
• المحركات الكهربائية مربع ومحركات دائرية متوفرة
• YE3 عالية الكفاءة للسيارات ، وحماية الصف IP55 واو
• غلاف المضخة مع طلاء مضاد للتآكل
• المكره مصنوعة من الفولاذ المقاوم للصدأ ايسي 304 أو الحديد الزهر

3D PRODUCT CHAT NOW

Product Specification (50HZ) 60HZ

Purity Pump Co., Ltd. is a specialized manufacturer and supplier of high-quality

industrial pumps, exporting to global market in competitive prices. We provide

various reliable pumps for projects. Our main products are centrifugal pumps, fire

pumps and system, industrial pumps and agricultural pumps.

Our products and services have been deployed in more than 55 countries.

And we supply water pumps for many large projects like National Olympic Stadium.

We also supply centrifugal and fire pumps to some well-known pump companies all

over the world.

Product Description

PSMF 详情图750.jpg

PSM(PS+YE3)

PSF 详情图750.jpg

YE3 详情图.jpg

TECHNICAL DESCRIPTION

New EN733 standard centrifugal pump

Original design by PURITY (patented)

Both square motor & round motor available

YE3 high efficient motor, with protection IP55 class F

Pump case with anti-corrosive coating

Impeller in stainless steel AISI 304 or cast iron

Shaft in stainless steel AISI 304 or galvanized iron

Galvanized counter flange with bolts, nuts and gaskets

Quality NSK bearing, wear resistance mechanical seal

APPLICATIONS

Suitable for use with clean water and liquids that are not chemically

aggressive towards the materials from which the pump is made.

The EN733 centrifugal pumps are recommended for use in water supply,

cleaning sets, pressure boosting, firefighting sets, irrigation, industrial

applications, water circulation in climatisation sets, agricultural.

USING LIMITS

Liquid temperature between -10℃ and +120℃

Ambient temperature up to +50℃

Max. working pressure 16 bar

Continuous service S1

PATENTS

Registered model PST

Registered Patent Design n° 201530478502.0

STANDARD IMPELLER MATERIAL

DISCHAEGE SIZE	IMPELLER SIZE
125	160	200	250	250D	315	400
32	SS304	SS304	SS304	Cast iron	SS304
40	Cast iron	Cast iron	Cast iron	Cast iron	/
50	Cast iron	Cast iron	Cast iron	Cast iron	/
65	Cast iron	Cast iron	Cast iron	Cast iron	/	Cast iron
80	Cast iron	Cast iron	Cast iron	Cast iron	/	Cast iron	Cast iron
100		Cast iron	Cast iron	Cast iron	/	Cast iron	Cast iron
125			Cast iron	Cast iron	/	Cast iron	Cast iron
150			Cast iron	Cast iron	/	Cast iron	Cast iron
200				Cast iron	/	Cast iron	Cast iron
250					/	Cast iron	Cast iron

TECHICAL DATA/DATOS TECNICOS

60 HZ n=3500 1/min

MODEL MODELO	Power Potencia		us gpm	Q=DELIVERY / CAUDAL																			DN
			us gpm	0	26	40	66	79	106	119	159	185	211	238	317	370	396	476	529	608	793	925
			l/min	0	100	150	250	300	400	450	600	700	800	900	1200	1400	1500	1800	2000	2300	3000	3500
	kw	hp	m³/h	0	6	9	15	18	24	27	36	42	48	54	72	84	90	108	120	138	180	210	mm
32-160/15	1.5	2	Head H(m)	25.4	23.7	22.5	18.5	15.8															50x32
32-160/22	2.2	3		31	29.6	28.5	24.5	22	15														50x32
32-160/30	3	4		35	34.3	34	28	25.5	19	15													50x32
32-200/30	3	4		44.2	43	39.8	35.2	32.2	24.6	19.8													50x32
32-200/40	4	5.5		54.5	52	50	45.5	41.9	35	30.3													50x32
32-250/55	5.5	7.5		60	59.5	59	55	53	49	46													50x32
32-250/75	7.5	10		75	74.5	74.3	73.5	72.5	68.5	67.3	60												50x32
32-250/110	11	15		90	87.5	85.8	82	79	75	72	65												50x32
40-160/30	3	4		31.8				29.5	27.5	26.3	21.5	17.5											65x40
40-160/40	4	5.5		38				36	34	33	28.5	25	20.1										65x40
40-200/55	5.5	7.5		46				43.8	41.3	40.1	35	30											65x40
40-200/75	7.5	10		57				53.6	51.5	50	45	41	36.5										65x40
40-250/92	9.2	12.5		64				59	56.5	55	49.5	45	39.8										65x40
40-250/110	11	15		78				75	73	72	67	63	56	43									65x40
40-250/150	15	20		88.5				83.5	80.5	79	74	70.5	65	52									65x40
50-125/22	2.2	3		17							15.4	14	12.8	11.5	6.5								65x50
50-125/30	3	4		20							18.8	18	17	15.6	11								65x50
50-125/40	4	5.5		24							23.1	23	21.5	20.3	15.8	11.8							65x50
50-160/55	5.5	7.5		32							30.6	30	28	26.6	20.5	14.8							65x50
50-160/75	7.5	10		40							38	37	36	34.4	29	24	21						65x50
50-200/92	9.2	12.5		50.5							46.8	45	43	40.9	32.5	26.7							65x50
50-200/110	11	15		57.5							53.5	52	50	47.5	40	34	29						65x50
50-200/150	15	20		62							58	56.5	54.5	52	44.5	39	35.5						65x50
50-250/150	15	20		68.5							64	63	61.5	59	50	41							65x50
50-250/185	18.5	25		79							75.8	74.8	74	71.5	63.5	55.5	47						65x50
50-250/220	22	30		89.5							86	85.3	84	81.5	73.5	65.5	57						65x50
65-125/40	4	5.5		19									17.3	16.8	14.5	13	11.8						80x65
65-125/55	5.5	7.5		23									21.3	20.9	19	17.5	16.7	13.7					80x65
65-125/75	7.5	10		27									26	25.6	24.5	23	22.5	20	18				80x65
65-160/92	9.2	12.5		33										31.5	30	28	27.1	24	21.5				80x65
65-160/110	11	15		36										34.5	33	31.5	30.8	28	25.5				80x65
65-160/150	15	20		42										41	40	38.5	37.8	35	33	29.5			80x65
65-200/150	15	20		45										45.5	43	41	40.2	36.5	34				80x65
65-200/185	18.5	25		52										52.3	51	49	48.2	44.5	42				80x65
65-200/220	22	30		59										59.5	58	56	55	52	49.5	44.5			80x65
65-250/220	22	30		64.8										64.7	62	60	58.5	53	50				80x65
65-250/300	30	40		80										79.8	77.5	75.5	74.5	70	66	58			80x65
65-250/370	37	50		92										90.5	88.5	87	85	80.5	78	68			80x65
65-315/370	37	50		102										99.2	97	95	94.5	92.4	90	83			80x65
65-315/450	45	60		112										109.2	107.7	105.8	104.5	102.5	100	93	66		80x65
65-315/550	55	75		122										119.2	117.4	115.7	114.5	112.5	110	103	76		80x65
65-315/750	75	100		141										139.8	137.3	135.6	134.5	132.5	130	122	96	65.5	80x65
80-125/40	4	5.5		17									16.5	15.9	14.3	13.5	11.6	10	7.5				100x80
80-125/55	5.5	7.5		21									20.5	20	19	18	16.5	15	12.5	9.5			100x80
80-125/75	7.5	10		26									25	25	24.5	23.8	22.5	21.5	19.5	16.5			100x80

TECHICAL DATA/DATOS TECNICOS

60 HZ n=3500 1/min

MODEL MODELO	Power Potencia		us gpm	Q=DELIVERY / CAUDAL																		DN
			us gpm	0	264	396	529	634	793	881	925	969	1057	1233	1322	1586	1762	2203	2643	3524	4405
			l/min	0	1000	1500	2000	2400	3000	3333	3500	3666	4000	4666	5000	6000	6666	8333	10000	13333	16666
	kw	hp	m³/h	0	60	90	120	144	180	200	210	220	240	280	300	360	400	500	600	800	1000	mm
80-160/110	11	15	Head H(m)	27	27	27.3	24.5	21.1	16													100x80
80-160/150	15	20		32.8	32.6	32.5	30.2	27	22.1	18.5	16.7											100x80
80-160/185	18.5	25		39	38.5	38	36.7	33.6	28.8	25.3	23.5											100x80
80-160/220	22	30		44	43.5	43	41.7	38.6	33.8	30.3	28.5											100x80
80-200/220	22	30		48	47.7	47.5	43.5	39.2	32.5	27.2	24.5											100x80
80-200/300	30	40		60	59.7	59.5	57	53.1	47	42.7	40.5											100x80
80-250/370	37	50		71.5	70.9	70.5	65.5	59.3	51	43.2	38.5											100x80
80-250/450	45	60		88	86.7	86	83.6	78.5	70.5	60	51											100x80
80-250/550	55	75		94.5	94.5	94.5	91.8	87	79.5	72.1	68.3											100x80
80-315/450	45	60		85	84	82.6	82	78	68.3	61	56											100x80
80-315/550	55	75		98	97	95.6	95	91	81.3	74	69											100x80
80-315/750	75	100		124	123	121.6	121	117	107.3	100	95	90	80.8									100x80
80-315/900	90	125		144	143	141.6	141	137	127.3	120	115	110	100.8									100x80
100-160/150	15	20		35	33.5	32.5	30	27.8	24.5	21.5	20	18.3	15									125x100
100-160/185	18.5	25		38.5	37.5	36.5	34.3	32.2	29	25.7	24	22	18									125x100
100-160/220	22	30		43	41	40	37.6	35.2	31.5	28.5	27	25.3	22									125x100
100-200/220	22	30		38.5	36.7	35.7	33.8	31.7	28.5	26.8	26	25	22.9	16.3	13							125x100
100-200/300	30	40		44.5	42.5	42	40.2	38.8	36.7	34.2	33	31.7	29	21.7	18							125x100
100-200/370	37	50		55	53	51	50.6	49.2	47	45	44	42.8	40.5	32.8	29							125x100
100-250/450	45	60		65	65	64	63	61	58	56	55	53.3	50	39	33.5							125x100
100-250/550	55	75		77	76	75.5	75	73.8	72	71.7	71.5	70.7	69	62.3	59							125x100
100-250/750	75	100		91	91	90.5	89.7	88	85.5	84	83.3	81.5	78	71.7	68.5	48						125x100
100-315/550	55	75		80			79	77.4	75	74	73.5	73	71.3	68	66	60						125x100
100-315/750	75	100		100			99	97.4	95	94	93.5	93	91.3	88	86	80						125x100
100-315/900	90	125		118			116.5	114.7	112	111	110.8	110.5	108.7	106	104	98						125x100
100-315/1100	110	150		138			136.5	134.7	132	131	130.8	130.5	128.7	126	124	118						125x100
125-200/450	45	60		39.8			39.3	39.2	39	38.9	38.9	38.8	37.5	35	34	28.6	25					150x125
125-200/550	55	75		49.8			49.3	49.2	49	48.9	48.9	48.8	47.5	45	44	38.6	35					150x125
125-200/750	75	100		60.8			60.3	60.2	60	59.9	59.9	59.8	58.5	56	55	49.6	46					150x125
125-250/550	55	75		70			67	65	64	63	62	61	59.5	57	56	53						150x125
125-250/750	75	100		80			77	75	74	73	72	71	69.8	67.1	66.2	63	58.5					150x125
125-250/900	90	125		87			84	82	81	80	79	78	77	74.5	73.5	70.2	65.7					150x125
125-250/1100	110	150		97			94	92	91	90	89	88	87	84.6	83.9	80.4	76					150x125
125-315/900	90	125		89						87	86	85	83.7	81.5	81	77	74	61				150x125
125-315/1100	110	150		103						101	100	99	97.8	95.5	95	91.5	88.2	75.6				150x125
125-315/1320	132	180		118						116	115	114	112.5	110.5	110.3	106.5	103.2	91				150x125
125-315/1600	160	220		138						136.8	135.9	135	133.7	131.5	131	127.5	124.2	112				150x125
150-200/750	75	100		50								48	47.9	47.6	47.2	46.7	46.4	40.6	36.8	25.2		200x150
150-200/900	90	125		56								54	53.9	53.6	53.2	52.7	52.4	48	42.8	31.2		200x150
150-200/1100	110	150		65.2								62	61.7	61.2	60.8	59.8	59.2	57.2	54	46		200x150
150-250/1100	110	150		67											64.2	62	60.6	55.8	49.8	33.8		200x150
150-250/1320	132	180		80.2											78.2	76.3	75	70.6	65	50.2	29.8	200x150
150-250/1600	160	220		90											88.4	87	86	82	77.2	62.4	42	200x150
150-315/1600	160	220		92											90	88.3	87.2	82.8	76.8	60.4		200x150
150-315/2000	200	270		111											110.6	108.7	107.4	103.4	98.2	83.4	62.2	200x150
150-315/2500	250	340		135											135.4	133.7	132.6	128.6	123.8	110.2	91	200x150

TECHICAL DATA/DATOS TECNICOS

60 HZ n=1750 1/min

MODEL MODELO	Power Potencia		us gpm	Q=DELIVERY / CAUDAL																		DN
			us gpm	0	106	119	132	159	185	198	220	264	317	370	396	423	476	617	661	881	1101
			l/min	0	400	450	500	600	700	750	833	1000	1200	1400	1500	1600	1800	2333	2500	3333	4166
	kw	hp	m³/h	0	24	27	30	36	42	45	50	60	72	84	90	96	108	140	150	200	250	mm
65-160/11	1.1	1.5	Head H(m)	8	7.5	7.4	7.3	7	6.6	6.3	5.8	4.8	3.4									80x65
65-160/15	1.5	2		9	8.5	8.4	8.3	8	7.6	7.4	6.9	6	4.6									80x65
65-160/22	2.2	3		10.3	9.9	9.9	9.8	9.5	9.2	9	8.6	7.8	6.5	5								80x65
65-200/15	1.5	2		10			9.6	9.1	8.5	8.2	7.6	6.4	4.6									80x65
65-200/22	2.2	3		12.4			12.2	11.8	11.3	11	10.4	9.3	7.6									80x65
65-200/30	3	4		14.4			14.3	13.8	13.4	13.1	12.5	11.3	9.6	7.5								80x65
65-250/30	3	4		15.4			14.6	13.9	13.1	12.6	11.6	9.7	6.7									80x65
65-250/40	4	5.5		19			18.3	17.8	17.2	16.9	16.1	14.4	11.7									80x65
65-250/55	5.5	7.5		22.3			21.3	20.9	20.3	19.9	19.2	17.7	15.1	12								80x65
65-315/40	4	5.5		18.6			17.9	17.3	16.7	16.2	15.2	13.3										80x65
65-315/55	5.5	7.5		22.1				21.2	20.6	20.2	19.2	17.3	14									80x65
65-315/75	7.5	10		26.5				25.6	25.2	24.9	24.3	23	20.8	17.6								80x65
65-315/110	11	15		34.8				34.2	33.9	33.7	33.2	32.1	30.2	27.4	25.6	23.7	18.7					80x65
80-160/15	1.5	2		7.2						7.1	6.9	6.4	5.5	4.6	4.1	3.5						100x80
80-160/22	2.2	3		8.5						8.6	8.4	8	7.4	6.6	6.2	5.7	5					100x80
80-200/30	3	4		11.2						11	10.7	10.1	9.2	8	7.3	6.6						100x80
80-200/40	4	5.5		13.8						13.8	13.6	13.3	12.4	11.3	10.7	10	9					100x80
80-250/40	4	5.5		16.5						16	15.6	14.8	13.2	11.4	10.2	9						100x80
80-250/55	5.5	7.5		19.8						19.5	19.1	18.4	17.2	15.5	14.5	13.5	11.1					100x80
80-250/75	7.5	10		23.6						23.5	23.2	22.5	21.3	19.9	19	18.1	16					100x80
80-250/110	11	15		27.6						27.5	27.2	26.5	25.3	23.9	23	22.1	20	15				100x80
80-315/55	5.5	7.5		19.7						19.1	18.8	18.1	16.8	15	13.9	12.8	10.1					100x80
80-315/75	7.5	10		24.6						23.9	23.6	23	21.9	20.4	19.5	18.6	16.3					100x80
80-315/110	11	15		29.9						29.4	29.2	28.8	28.1	27	26.3	25.5	23.6	16.5	13.5			100x80
80-315/150	15	20		36.8						36.4	36.1	35.6	34.7	33.6	33	32.4	30.9	25.3	23			100x80
80-400/185	18.5	25		40.3						39.7	39.5	39.1	38.4	37.3	36.6	35.9	34.1	27.3	24.5			100x80
80-400/220	22	30		45.1						44.6	44.5	44.2	43.6	42.6	42	41.4	39.8	33.4	30.7			100x80
80-400/300	30	40		55.1						54.7	54.6	54.4	54	53.3	52.8	52.2	50.9	45.4	43.2			100x80
100-160/22	2.2	3		5.9						5.8	5.7	5.5	5.3	5	4.9	4.6	4.3					125x100
100-160/30	3	4		8.2						8.1	8	7.9	7.6	7.3	7.2	6.9	6.5	5.1				125x100
100-160/40	4	5.5		10						10	9.9	9.7	9.4	9.1	9	8.7	8.3	6.9	6.3			125x100
100-200/40	4	5.5		11.8						11.7	11.6	11.4	11	10.5	10.3	9.7	9.1	6.8	5.9			125x100
100-200/55	5.5	7.5		14.8						14.7	14.7	14.5	14.2	13.9	13.8	13.5	13	11.1	10.3			125x100
100-250/55	5.5	7.5		15.9						15.8	15.7	15.5	14.9	14.4	14.1	13.4	12.5	9.2	7.9			125x100
100-250/75	7.5	10		19.5						19.5	19.4	19.2	18.8	18.3	18.1	17.6	16.9	14	12.7			125x100
100-250/110	11	15		24.3						24.3	24.2	24.1	23.7	23.3	23.1	22.7	22.1	19.7	18.6	11.4		125x100
100-250/150	15	20		27.8						27.8	27.7	27.6	27.2	26.8	26.6	26.2	25.6	23.2	22.1	14.9		125x100
100-315/150	15	20		29.9							29.7	29.5	29.1	28.8	28.6	28.1	27.5	25	24	16.8		125x100
100-315/185	18.5	25		35							34.4	34.2	33.8	33.5	33.3	32.8	32.2	30	29	22.4		125x100
100-315/220	22	30		37							36.8	36.7	36.4	36.1	35.9	35.5	35.1	33.2	32.4	26.6		125x100
100-315/300	30	40		42							41.8	41.7	41.4	41.1	40.9	40.5	40.1	38.2	37.4	31.6		125x100
100-400/300	30	40		46.4								46	46	46	46	45	44	42	40	29.6		125x100
100-400/370	37	50		51.8								51.3	51.2	51.1	51	50.5	49.5	47.5	46	37.3		125x100
100-400/450	45	60		57.1								56.7	56.4	56.1	56	56	55	53	52	45	32.1	125x100

TECHICAL DATA/DATOS TECNICOS

60 HZ n=1750 1/min

MODEL MODELO	Power Potencia		us gpm	Q=DELIVERY / CAUDAL																	DN
			us gpm	0	132	154	176	220	264	396	441	485	617	661	881	1101	1322	1762	2203	2643
			l/min	0	500	583	667	833	1000	1500	1667	1833	2333	2500	3333	4167	5000	6667	8333	10000
	kw	hp	m³/h	0	30	35	40	50	60	90	100	110	140	150	200	250	300	400	500	600	mm
125-200/55	5.5	7.5	Head H(m)	11.4	11.1	11.1	11	10.9	10.8	10.2	10	9.7	8.9	8.6	6.9						150x125
125-200/75	7.5	10		14.1	13.9	13.8	13.8	13.7	13.6	13.1	12.9	12.7	11.9	11.6	9.6						150x125
125-200/110	11	15		18.1	17.9	17.8	17.8	17.7	17.6	17.1	16.9	16.7	15.9	15.6	13.6	9.8					150x125
125-250/75	7.5	10		15.4					15.3	15	14.8	14.6	13.6	13.1							150x125
125-250/110	11	15		19.4					19.3	19.1	19	18.9	18.1	17.8	15.3	11.7					150x125
125-250/150	15	20		23.2					23.3	23.1	23	22.9	22	22	19.8	16.5	12.3				150x125
125-250/185	18.5	25		25.6					25.5	25.5	25.4	25.3	24.9	24.7	23	20.3	16.5				150x125
125-315/185	18.5	25		27.3							26.9	26.7	25.9	25.6	23.3	19.7	14.9				150x125
125-315/220	22	30		30							29.7	29.6	28.9	28.6	26.5	23.2	18.4				150x125
125-315/300	30	40		35.6							35.4	35.3	34.8	34.6	32.9	30.1	26.1				150x125
125-315/370	37	50		38.2							38	37.9	37.4	37.2	35.7	33.1	29.4	17.8			150x125
125-400/220	22	30		33.4						32.8	32.5	32.1	30.5	29.7	24.7	17.3					150x125
125-400/300	30	40		41						41	40.5	40.3	39.2	38.6	34.4	27.5	18.3				150x125
125-400/370	37	50		46.2						46	45.7	45.5	44.6	44.2	40.7	34.8	26.5				150x125
125-400/450	45	60		51.4						51	50.9	50.8	50.1	49.8	47	42.2	34.8				150x125
125-400/550	55	75		56.5						56.3	56.3	56.2	55.9	55.7	53.8	50.3	44.7	26.7			150x125
150-200/110	11	15		14								13.5	13.4	13.3	13.1	12.9	11.7	7.8			200x150
150-200/150	15	20		16.3								15.5	15.3	15.2	14.8	14.3	13.5	11.1			200x150
150-200/185	18.5	25		18.3								17.5	17.3	17.2	16.8	16.3	15.5	13.1	10		200x150
150-250/150	15	20		17.5										16.8	15.9	14.7	13.2	9.2			200x150
150-250/185	18.5	25		21.3										20.8	20	18.9	17.5	13.8	8.7		200x150
150-250/220	22	30		24										23.6	23	22	20.8	17.1	12		200x150
150-250/300	30	40		25.5										25	24.5	23.5	22	18.8	13.8		200x150
150-315/300	30	40		30.2										29.7	29	27.9	26.4	22.3			200x150
150-315/370	37	50		33.6										33.5	32.7	31.7	30.4	26.7	21.4		200x150
150-315/450	45	60		37.7										37.6	36.9	35.9	34.7	31.3	26.5		200x150
150-315/550	55	75		40										40	39.3	38.4	37.2	33.9	29.4		200x150
150-315/750	75	100		45										45	44.3	43.4	42.2	38.9	34.4	27	200x150
150-400/550	55	75		48.2									47.7	48	46	45	42	36.8	29.2		200x150
150-400/750	75	100		55.4									55	55	54	53	51	47	41	32.2	200x150
150-400/900	90	125		59.5									59	59	58	57	56	52	46	37.7	200x150
150-400/1100	110	150		65.5									65	65	64	63	62	58	52	43.7	200x150

MODEL MODELO	Power Potencia		us gpm	Q=DELIVERY / CAUDAL														DN
			us gpm	0	604	991	1374	1762	2145	2533	2916	3304	3687	4075	4564	5075	5586
			l/min	0	2283	3750	5200	6667	8117	9583	11033	12500	13950	15417	17267	19200	21133
	kw	hp	m³/h	0	137	225	312	400	487	575	662	750	837	925	1036	1152	1268	mm
200-250/185	18.5	25	H(m)	15.7	15.3	14.8	13.7	12.2	10.6	8.9	6.8							250x200
200-250/220	22	30		18.5		17.2	16.2	14.8	13.1	11.1	8.7							250x200
200-250/300	30	40		23.1		21.5	20.5	19.4	17.9	16	13.6	10.8						250x200
200-315/550	55	75		31.1		30.2	29.8	29.1	27.9	25.8	23	19.2	14.8					250x200
200-315/750	75	100		35.1		34.3	34	33.3	32	29.9	27.1	23.4	19.1					250x200
200-315/900	90	125		42.1		41.3	41	40.3	39	36.9	34.1	30.4	26.1					250x200
200-400/750	75	100		41		40.6	40.3	39.4	37.7	35	31.3	26.5						250x200
200-400/900	90	125		46.5		46	45.7	44.9	43.4	41.1	37.7	33.3	27.9					250x200
200-400/1100	110	150		52.4		52.2	51.9	51.2	50	48	45.1	41.2	36.2					250x200
200-400/1320	132	180		60.1		59.8	59.6	59	57.9	56.1	53.5	50	45.4	39.6				250x200
250-315/550	55	75		26.1			24.9	24.5	24.1	23.6	22.8	21.6	19.9	18	14.5			300x250
250-315/750	75	100		35.4			35.2	34.7	33.8	32.5	30.4	28	25	21.8	16.4			300x250
250-315/900	90	125		39.8			39.8	39.5	38.8	37.9	36	33.9	31	27.9	22.5			300x250
250-400/1100	110	150		45.1			45	44.9	44.5	43.8	42.3	40.5	37.9	35.1	30	23.9		300x250
250-400/1320	132	180		50.8			50.6	50.5	50.2	49.7	48.4	46.8	44.5	42	37.3	31.5		300x250
250-400/1600	160	220		56.9			56.4	56.3	56	55.6	54.5	53.1	51.1	48.9	44.7	39.4	33	300x250

YE3
TECHNICAL DATA

MODEL	Power		rpm	η%	η% at 75%	η% at 50%	cosɸ	A			Nm	Tmax/Tn	Ts/Tn	Is/n	kg
MODEL	kw	hp	rpm	η%	η% at 75%	η% at 50%	cosɸ	380V	400V	415V	Nm	Tmax/Tn	Ts/Tn	Is/n	kg
YE3-801-2	0.75	1	2880	80.7	80.7	79.1	0.82	1.72	1.64	1.58	2.49	2.3	2.3	7.0	18.1
YE3-802-2	1.1	1.5	2880	82.7	82.7	81.0	0.83	2.43	2.31	2.23	3.65	2.2	2.3	7.3	19.5
YE3-90S-2	1.5	2	2895	84.2	84.2	82.5	0.84	3.22	3.06	2.95	4.95	2.2	2.3	7.6	23.3
YE3-90L-2	2.2	3	2895	85.9	85.9	84.2	0.85	4.58	4.35	4.19	7.26	2.2	2.3	7.6	27.1
YE3-100L-2	3	4	2895	87.1	87.1	85.4	0.87	6.02	5.71	5.51	9.90	2.2	2.3	7.8	38.8
YE3-112M-2	4	5.5	2905	88.1	88.1	86.3	0.88	7.84	7.45	7.18	13.1	2.2	2.3	8.3	48.3
YE3-132S1-2	5.5	7.5	2930	89.2	89.2	87.4	0.88	10.6	10.1	9.75	17.9	2.0	2.3	8.3	55.1
YE3-132S-2	7.5	10	2930	90.1	90.1	88.3	0.88	14.4	13.7	13.2	24.4	2.0	2.3	7.9	69.2
YE3-160M1-2	11	15	2945	91.2	91.2	89.4	0.89	20.6	19.6	18.9	35.7	2.0	2.3	8.1	113
YE3-160M2-2	15	20	2945	91.9	91.9	90.1	0.89	27.9	26.5	25.5	48.6	2.0	2.3	8.1	123
YE3-160L-2	18.5	25	2940	92.4	92.4	90.6	0.89	34.2	32.5	31.3	60.1	2.0	2.3	8.2	142
YE3-180M-2	22	30	2955	92.7	92.7	90.8	0.89	40.5	38.5	37.1	71.1	2.0	2.3	8.2	182
YE3-200L1-2	30	40	2960	93.3	93.3	91.4	0.89	54.9	52.1	50.3	96.8	2.0	2.3	7.6	246
YE3-200L2-2	37	50	2960	93.7	93.7	91.8	0.89	67.4	64.0	61.7	119.4	2.0	2.3	7.6	265
YE3-225M-2	45	60	2965	94.0	94.0	92.1	0.90	80.8	76.8	74.0	144.9	2.0	2.3	7.7	323
YE3-250M-2	55	75	2970	94.3	94.3	92.4	0.90	98.5	93.5	90.2	176.9	2.0	2.3	7.7	413
YE3-280S-2	75	100	2975	94.7	94.7	92.8	0.90	134	127	122	240.8	1.8	2.3	7.1	546
YE3-280M-2	90	125	2975	95.0	95.0	93.1	0.90	160	152	146	288.9	1.8	2.3	7.1	569
YE3-315S-2	110	150	2978	95.2	95.2	93.3	0.90	195	185	179	352.8	1.8	2.3	7.1	897
YE3-315M-2	132	180	2978	95.4	95.4	93.5	0.90	234	222	214	423.3	1.8	2.3	7.1	1029
YE3-315L1-2	160	220	2980	95.6	95.6	93.7	0.91	279	265	256	512.8	1.8	2.3	7.2	1067
YE3-315L2-2	200	270	2980	95.8	95.8	93.9	0.91	349	331	319	640.9	1.8	2.2	7.2	1194
YE3-355M-2	250	340	2982	95.8	95.8	93.9	0.91	436	414	399	800.6	1.6	2.2	7.2	1685
YE3-355L-2	315	430	2982	95.8	95.8	93.9	0.91	549	522	503	1009	1.6	2.2	7.2	1734

PS 1

No.	Description	Material	No.	Description	Material	No.	Description	Material
1	Pump Case	Cast iron	8	Bearing	Ball Bearing	15	Impeller Key	Iron
2	Impeller	SS304/Cast iron	9	Support Case	Cast iron	16	Connection Bolt	Steel
3	Mechanical Seal	SiC/Carbon/SS304	10	Support Foot	Iron	17	Impeller Nut	Galvanizated Steel
4	O-ring	Rubber	11	Foot Bolt	Steel	18	Release Valve	Brass
5	Connection	Cast iron	12	Coupling(Optional)	Steel	19	Gasket	Rubber
6	Shaft	SS304/45# Steel	13	Case Cover	SS304	20	Counter Flange	Galvanizated Cast iron
7	Bearing Cover	Cast iron	14	Nameplate	Aluminum	21	Flange Bolt	Steel
